15.7 Version
15.7.1 Displaying version data
The following components with the associated version data are specified in the "Version data"
window:
● System software
● PLC basic program
● PLC user program
● System expansions
● OEM applications
● Hardware
Information is provided in the "Nominal version" column as to whether the versions of the
components deviate from the version supplied on the CompactFlash Card.
The version displayed in the "Actual version" column matches the version of the
CF card.
The version displayed in the "Actual version" column does not match the ver‐
sion of the CF card.
You may save the version data. Version data saved as text files can be further processed as
required or sent to the hotline in the event of an error.
Procedure
1. Select the "Diagnostics" operating area.
2. Press the "Version" softkey.
The "Version Data" window appears.
Data of the available components is displayed.
3. Select the component for which you would like more information.
4. Press the "Details" softkey, in order to receive more exact information on
the components displayed.
Alarm, error and system messages
15.7 Version
Turning
Operating Manual, 06/2019, A5E44903486B AB 847
