13.14 Settings for tool lists
In the "Settings" window you have the following options to set the view in the tool lists:
● Display only one magazine in "Magazine sort"
– You can limit the display to one magazine. The magazine is displayed with the assigned
buffer magazine locations and the tools not loaded.
– You may set via a configuration if you want to jump to the next magazine by clicking
softkey "Magazine selection" or if the dialog "Magazine selection" is switched over to any
magazine.
● Display only spindle in buffer.
In order to display only the spindle location during operation, the remaining locations of the
buffer are hidden.
● Permitting tool in/out file
– When creating a new tool, the tool data can be loaded from a file.
– When deleting or unloading a tool, the tool data can be backed up to a file.
● Switch on adapter-transformed view
– Geometry lengths and the application offsets are displayed in a transformed manner in
the tool list.
– In the tool wear list, the wear length and the sum offsets are displayed in a transformed
manner.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
References
For further information about configuring the settings, please refer to the following references:
SINUMERIK Operate (IM9) / SINUMERIK 840D sl Commissioning Manual
Procedure
1. Select the "Parameter" operating area.
...
2. Press the "Tool list", "Tool wear" or "Magazine" softkey.
Tool management
13.14 Settings for tool lists
Turning
Operating Manual, 06/2019, A5E44903486B AB 763
