See also
Actual value window (Page 45)
4.8.1 Display active zero offset
The following zero offsets are displayed in the "Zero Offset - Active" window:
● Zero offsets, for which active offsets are included, or for which values are entered.
● Settable zero offsets
● Total zero offset
This window is generally used only for monitoring.
The availability of the offsets depends on the setting.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Zero offset" softkey.
The "Zero Offset - Active" window is opened.
Note
Further details on zero offsets
If you would like to see further details about the specified offsets or if you would like to change
values for the rotation, scaling or mirroring, press the "Details" softkey.
4.8.2 Displaying the zero offset "overview"
The active offsets or system offsets are displayed for all axes that have been set up in the "Work
offset - overview" window.
Setting up the machine
4.8 Zero offsets
Turning
118 Operating Manual, 06/2019, A5E44903486B AB
