5.8 Default settings for manual mode

Specify the configurations for the manual mode in the "Settings for manual operation" window.

Default settings

Settings Meaning

Type of feedrate Here, you select the type of feedrate.

● G94: Axis feedrate/linear feedrate

● G95: Revolutional feedrate

Setup feedrate G94 Enter the desired feedrate in mm/min.

Setup feedrate G95 Enter the desired feedrate in mm/rev.

Variable increment For variable increments, enter the desired increment when traversing axes.

Spindle speed Here, enter the desired spindle speed in rpm.

Procedure

1. Select the "Machine" operating area.

2. Press the <JOG> key.

3. Press the menu forward key and the "Settings" softkey.

The "Settings for manual operation" window is opened.

See also

Switching the unit of measurement (Page 101)

Working in manual mode

5.8 Default settings for manual mode

Turning

152 Operating Manual, 06/2019, A5E44903486B AB
