Note:
The thread synchronization is activated by teaching in a spindle. In this
case, the synchronizing positions of axes X and Z and the synchronizing
angle of spindle (Sn) are saved in the Machine and displayed in the
screen form.
The selection boxes for main spindle and counterspindle indicate wheth‐
er thread synchronization is active for the particular spindle (yes = active /
no = not active).
5. Now carry out the "thread turning" machining step.
6. For the main spindle or counterspindle, select the "no" entry to deactivate
thread synchronization.
Working in manual mode
5.7 Thread synchronizing
Turning
Operating Manual, 06/2019, A5E44903486B AB 151
