17.4 Swiveling
General sequence
● Swivel the coordinate system into the plane to be machined via the swivel screen.
● Machining with the setting “Face B”.
● If another machining type follows, swiveling is automatically deselected.
The swiveled coordinates are maintained in the reset state and after Power On. So you can still
move out of an inclined hole, for example, with retraction in the +Z direction.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Swiveling is executed one axis at a time. In the case of axis-by-axis swiveling, the coordinate
system is rotated around each axis in turn, with each rotation starting from the previous rotation.
The axis sequence can be freely selected.
Procedure
1. The "Spigot Res. Mat." input window opens if you press the "Various"
softkey.
2. Press the "Swivel plane" softkey.
3. Press the "Initial position" softkey if you wish to reestablish the basic
setting, i.e. you wish to set the values back to 0.
This is done, for example, to swivel the coordinate system back to its
original orientation.
Parameter Description Unit
T Tool identifier
RP Retraction plane for face B mm
C0 Positioning angle for machining surface Degrees
X0 Reference point for rotation mm
Y0 Reference point for rotation mm
Z0 Reference point for rotation mm
Swivel mode
● axis-by-axis: Swivel coordinate system axis-by-axis
● Solid angle: Swivel via solid angle
● Proj. angle: Swiveling via projection angle
● Direct: Position rotary axes directly
Axis sequence Sequence of the axes which are rotated around - (only for axis-by-axis swivel mode)
XYZ or XZY or YXZ or YZX or ZXY or ZYX
Working with a B axis (only 840D sl)
17.4 Swiveling
Turning
880 Operating Manual, 06/2019, A5E44903486B AB
