4.2 Approaching a reference point
4.2.1 Referencing axes
Your machine tool can be equipped with an absolute or incremental path measuring system. An
axis with incremental path measuring system must be referenced after the controller has been
switched on – however, an absolute path measuring system does not have to be referenced.
For the incremental path measuring system, all the machine axes must therefore first approach
a reference point, the coordinates of which are known to be relative to the machine zero-point.
Sequence
Prior to the approach, the axes must be in a position from where they can approach the
reference point without a collision.
The axes can also all approach the reference point simultaneously, depending on the
manufacturer’s settings.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
NOTICE
Risk of collision
If the axes are not in a collision-free position, you must first traverse them to safe positions in
"JOG" or "MDI" mode.
You must follow the axis motions directly on the machine!
Ignore the actual value display until the axes have been referenced!
The software limit switches are not active!
Procedure
1. Press the <JOG> key.
2. Press the <REF. POINT>. key
3. Select the axis to be traversed.
Setting up the machine
4.2 Approaching a reference point
Turning
94 Operating Manual, 06/2019, A5E44903486B AB
