Displaying/hiding a multi-channel view
1. Select the "Machine" operating area
...
2. Select the "JOG", "MDA" or "AUTO" mode.
3. Press the menu forward key and the "Settings" softkey.
4. Press the "Multi-channel view" softkey.
5. In the window "Settings for Multi-Channel View" in the selection
box "View", select the required entry (e.g. "2 channels") and define
the channels as well as the sequence in which they are to be
displayed.
In the basic screen for the "AUTO", "MDA" and JOG" operating
modes, the upper window of the left-hand and right-hand channel
columns are occupied by the actual value window.
6. Press the "T,F,S" softkey if you wish to view the "T,F,S" window.
The "T,F,S" window is displayed in the lower window of the left-
hand and right-hand channel column.
Note:
The "T,F,S" softkey is present only for smaller operator panels, i.e.
up to OP012.
See also
Setting the multi-channel view (Page 665)
11.1.2 Multi-channel view for large operator panels
On the OP015 and OP019 operator panels as well as on the PC, you have the option of
displaying up to four channels next to each one. This simplifies the creation and run-in for multi-
channel programs.
Multi-channel machining
11.1 Multi-channel view
Turning
Operating Manual, 06/2019, A5E44903486B AB 663
