Num‐
ber
Integer component
Num‐
ber
Conversion between millimeters and inches
1. Enter the numerical value.
2. Press the "MM" key to convert inches to millimeters.
The key is highlighted in blue.
- OR -
Press the "INCH" key to convert millimeters to inches.
The button is highlighted in blue.
3. Press the "=" key on the calculator.
The calculated value is displayed in the entry field. The key for the unit is
highlighted in gray once again.
2.4.10 Context menu
When you right-click, the context menu opens and provides the following functions:
● Cut
Cut Ctrl+X
● Copy
Copy Ctrl+C
● Paste
Paste Ctrl+V
Program editor
Additional functions are available in the editor
● Undo the last change
Undo Ctrl+Z
● Redo the changes that were undone
Redo Ctrl+Y
Up to 50 changes can be undone.
Introduction
2.4 User interface
Turning
56 Operating Manual, 06/2019, A5E44903486B AB
