Note
Predrilling position
The position at which inserting takes place if "predrilled" is selected is the same position that
you select if the reference point "inside left" is specified. In the case of a groove without an angle
of rotation, the predrilling position is the center point of the left rounding radius of the groove.
When calling the cycle on a position circle, the predrilling position is always the center point of
the rounding radius that is closer to the center of the circle.
* Unit of feedrate as programmed before the cycle call
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can be
adjusted using setting data.
Parameter Description Value Can be set in SD
PL (only for G code) Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Reference point
(only for G code)
Position of the reference point: Center
Machining
position (only for G
code)
Mill slot at the programmed position (X0, Y0, Z0) Single posi‐
tion
α0 Angle of rotation 0°
Machine manufacturer
Please refer to the machine manufacturer's specifications.
10.4.8 Circumferential groove (SLOT2)
Function
You can mill one or several circumferential slots of equal size on a full or pitch circle with the
"circumferential slot" cycle.
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 533
