Parameters Description Unit
Transition to next ele‐
ment
Type of transition
● Radius
● Chamfer
Radius R Transition to following element - radius mm
Chamfer FS Transition to following element - chamfer mm
Additional commands Additional G code commands
Contour element "Pole"
Parameters Description Unit
Machining
surface
(only for ShopTurn)
● Face C
● Face Y
● Face B
● Peripheral surface C
● Peripheral surface Y
X
Y
Position pole (abs)
Position pole (abs)
mm (in)
Degrees
Contour element "End"
The data for the transition at the contour end of the previous contour element is displayed in the
"End" parameter screen.
The values cannot be edited.
10.5.5 Changing the contour
Function
You can change a previously created contour later.
If you want to create a contour that is similar to an existing contour, you can copy the existing
one, rename it and just alter selected contour elements.
Individual contour elements can be
● added,
● changed,
● inserted or
● deleted.
Programming technology functions (cycles)
10.5 Contour milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 573
