4. Press the "Hide position" softkey.
The "Hide position" window opens on top of the input form of the position
pattern.
The positions are displayed in a table.
The numbers of the positions, their coordinates (X, Y) as well as a
checkbox with the state (activated = on / deactivated = off) are displayed.
The actual position in the graphic is highlighted in color.
5. Using the mouse, select the required position and deactivate or activate
the checkbox in order to hide the position or display it again.
In the diagram, skipped positions are shown in the form of a circle and
displayed (active) positions are shown in the form of a cross.
Note: You have the option of selecting individual positions using the
<Cursor up> or <Cursor down> keys – and hiding and displaying using
the <SELECT> key.
Display or hide all positions at once
1. Press the "Hide all" softkey to hide all positions.
2. Press the "Show all" softkey to display all positions again.
10.1.16 Repeating positions
Function
If you want to approach positions that you have already programmed again, you can do this
quickly with the function "Repeat position".
You must specify the number of the position pattern. The cycle automatically assigns this
number (for ShopTurn). You will find this position pattern number in the work plan (program
view) or G-code program after the block number.
Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Drilling", and "Repeat position" softkeys.
The "Repeat positions" input window opens.
3. After you have entered the label or the position pattern number, e.g. 1,
press the "Accept" softkey. The position pattern you have selected is
then approached again.
Programming technology functions (cycles)
10.1 Drilling
Turning
404 Operating Manual, 06/2019, A5E44903486B AB
