9.17 Programming retraction to tool change point
You can approach the tool change point directly using the "Tool change point" softkey.
The retraction planes are taken into account. This makes good sense when moving the tool to
a "safe" position, for example.
Procedure
1. The ShopTurn program to be processed has been created and you are
in the editor.
2. Press the menu forward key and the "Straight Circle" softkey.
3. Press the "Tool change point" softkey.
The "Tool change point" window opens.
4. Press the "Accept" softkey in order to approach the tool change point
directly.
Parameter Description Unit
Retraction to tool
change point
The tool change point is automatically approached.
Creating a ShopTurn program
9.17 Programming retraction to tool change point
Turning
324 Operating Manual, 06/2019, A5E44903486B AB
