Parameter

The parameters of the input screen forms correspond to the parameters under Automatic (see

Section "Drilling (Page 345)").

16.6.2 Turning with manual machine

Functions (cycles)

The same range of technological functions (cycles) is available for turning as in the automatic

mode:

⇒ ⇒

Working with Manual Machine

16.6 More complex machining

Turning

Operating Manual, 06/2019, A5E44903486B AB 869
