17.2 Tool alignment for turning
The input fields for the β and γ angles for aligning the tool are available in the tool screen and
in all turning screens.
β angle
In the entry field "β" you have the possibility of selecting the main alignment of the tool:
● : β = 0°
● : β = 90°
● Empty : The required angle can be freely entered
Programming when machining with a counter-spindle
When machining on the counter-spindle, it is programmed in exactly the same way as the main
spindle.
The direction display of the arrows depends on the settings.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
γ angle
In the entry field "γ" you have the possibility of selecting the main alignment of the tool:
● 0°
● 180°
- or -
● Free entry field to enter the required angle
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Working with a B axis (only 840D sl)
17.2 Tool alignment for turning
Turning
878 Operating Manual, 06/2019, A5E44903486B AB
