Further information
Further information about the contour tolerance and configuring the displayed G groups can be
found at:
● Basic Functions Function Manual: Chapter "Contour/Orientation Tolerance"
● SINUMERIK Operate Commissioning Manual
Procedure
1. Select the "Machine" operating area
2. Press the <JOG>, <MDI> or <AUTO> key.
3. Press the ">>" and "All G functions" softkeys.
The "G Functions" window is opened.
See also
High-speed settings (CYCLE832) (Page 617)
6.13.4 Auxiliary functions
Auxiliary functions include M and H functions preprogrammed by the machine manufacturer,
which transfer parameters to the PLC to trigger reactions defined by the manufacturer.
Displayed auxiliary functions
Up to five current M functions and three H functions are displayed in the "Auxiliary Functions"
window.
Machining the workpiece
6.13 Displaying G functions and auxiliary functions
Turning
Operating Manual, 06/2019, A5E44903486B AB 217
