New C axis rotation Additive C axis rotation

Parameter Description Unit

Rotation

● New

New rotation

● Additive

Additive rotation

C Rotation C Degrees

10.7.9 Straight and circular machining

If you want to perform simple, i.e. straight or circular path movements or machining without

defining a complete contour, you can use the functions "Straight" or "Circle" respectively.

General sequence

To program simple machining operations, proceed as follows:

● Specify the tool and the spindle speed

● Program the machining operations

Machining options

The following machining options are available:

● Straight line

● Circle with known center point

● Circle with known radius

Programming technology functions (cycles)

10.7 Additional cycles and functions in ShopTurn

Turning

Operating Manual, 06/2019, A5E44903486B AB 637
