Configure ABC keyboard and MCP

If you configured ABC keyboard and MCP keys, then the navigation bar is extended for the

sidescreen:

Operator control Function

Display of standard widgets in the sidescreen

Display of an ABC keyboard on the sidescreen

Display of a machine control panel on the sidescreen

3.5.14 Example 1: ABC keyboard in the sidescreen





① ABC keyboard

② Key to display the keyboard

Multitouch operation with SINUMERIK Operate

3.5 Expansion with side screen

Turning

86 Operating Manual, 06/2019, A5E44903486B AB
