9.9 Call work offsets

You can call work offsets (G54, etc.) from any program.

You define work offsets in work offset lists. You can also view the coordinates of the selected

offset here.

Procedure

1. Press the "Various", "Transformations" and "Work offset" softkeys.

The "Work offset" window opens.

2. Select the desired work offset (e.g. G54).

3. Press the "Accept" softkey.

The work offset is transferred into the work plan.

Creating a ShopTurn program

9.9 Call work offsets

Turning

Operating Manual, 06/2019, A5E44903486B AB 307
