Parameter Description
Drilling depth
● Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
● Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value programmed
for Z1.
Note: If it is not possible to define an angle for the drill in the tool management, it will not
be possible to select tip or shank (always tip, 0 field).
Z0 (only for G code) Reference point Z mm
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc).
It is inserted into the workpiece until it reaches Z1.
DT Dwell time at final drilling depth s
rev
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can be
adjusted using setting data.
Parameter Description Value Can be set in SD
PL (only for G code) Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Predrilling
ZA Predrilling depth
FA Reduced predrilling feedrate
Through drilling
ZD Depth for reduced feedrate
FD Reduced through drilling feedrate
Machine manufacturer
Please refer to the machine manufacturer's specifications.
10.1.4 Reaming (CYCLE85)
Function
With the "Reaming" cycle, the tool is inserted in the workpiece with the programmed spindle
speed and the feedrate programmed at F.
If Z1 has been reached and the dwell time expired, the reamer is retracted at the programmed
retraction feedrate to the retraction plane.
Programming technology functions (cycles)
10.1 Drilling
Turning
352 Operating Manual, 06/2019, A5E44903486B AB
