7. Press the <+> or <-> key on the machine control panel.
... - OR -
Select the direction with the aid of the cross-switching lever.
The axes are moved at the set machining feedrate.
Note:
Please refer to the machine manufacturer's specifications.
The active direction is graphically displayed in the basic screen by means
of the wind rose.
16.5.2 Taper turning
The basic effective direction can be selected via the axis direction keys or via the cross-
switching lever. In addition, a taper angle (α1) can also be entered.
Procedure
1. "Manual Machine" is active.
2. Press the "Taper turning" softkey.
3. Select the tool, spindle, and spindle direction and specify the machining
feedrate.
4. Enter the desired angle α1.
Note
Selecting/deselecting the taper turning and changing the angle α1 is only possible in the reset
state.
Parameter Description Unit
T Tool name
D Cutting edge number
ST
F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting rate rev/min
m/min
Working with Manual Machine
16.5 Simple workpiece machining
Turning
Operating Manual, 06/2019, A5E44903486B AB 863
