4.12.4 Deleting an MDA program

Precondition

The MDA editor contains a program that you created in the MDI window or loaded from the

program manager.

Procedure

Press the "Delete blocks" softkey.

The program blocks displayed in the program window are deleted.

Setting up the machine

4.12 MDA

Turning

136 Operating Manual, 06/2019, A5E44903486B AB
