4. Press the "OK" softkey to relocate the tool to the recommended maga‐
zine location.
- OR -
Enter the required magazine number in the "...magazine" field and the
required magazine location number in "Location" field.
Press the "OK" softkey.
The tool is relocated to the specified magazine location.
Several magazines
If you have set up several magazines, then the "...relocate from magazine... location... to..."
window appears after pressing the "Relocate" softkey.
Select the desired magazine and location, and confirm your selection with "OK" to load the tool.
13.8.3 Delete/unload/load/relocate all tools
You have the option of deleting all tools from the magazine list, unloading all tools from the
magazine list, loading all tools to the magazine, or relocating tools simultaneously.
Preconditions
The following requirements must be met so that the "Delete all," "Unload all," "Load all," or
"Relocate all" softkey is displayed and is available:
● Magazine management is set up
● There is no tool in the buffer / in the spindle
Machine manufacturer
Please observe the information provided by the machine manufacturer.
Procedure
1. The magazine list is opened.
2. Press the "Delete all" softkey.
- OR -
Press the "Unload all" softkey.
- OR -
Press the "Load all" softkey.
Tool management
13.8 Magazine
Turning
Operating Manual, 06/2019, A5E44903486B AB 751
