Parameters Description Unit
X Target position X ∅ (abs) or target position X referred to the last programmed posi‐
tion (inc)
mm
Y Target position Y (abs) or target position Y referred to the last programmed position
(inc)
mm
Z Target position Z (abs) or target position Z referred to the last programmed position
(inc)
mm
U Target position (abs) or target position referred to the actual position (inc) mm
C Target angle (abs) or target angle referred to the actual position (inc) Degrees
C1 Target position of C axis of main spindle (abs or inc) mm
C3 Target position of C axis of counterspindle (abs or inc) mm
Z3 Target position of special axis (abs or inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
AWZ Target angle (abs) or target angle referred to the actual position (inc) Degrees
GS Target angle (abs) or target angle referred to the actual position (inc) Degrees
F Machining feedrate
Alternatively, rapid traverse
mm/rev
mm/min
mm/tooth
Radius compensation Input defining which side of the contour the cutter travels in the traversing direction:
Radius compensation to right of contour
Radius compensation to left of contour
Radius compensation off
The previously programmed setting for radius compensation is used.
10.7.12 Programming a circle with known center point
To program a circle or arc with a known center point, use the "Circle center point" function.
The tool traverses a circular path from its actual position to the programmed target position at
the machining feedrate. The system calculates the radius of the circle/arc on the basis of the
entered interpolation parameter settings I and K.
Programming technology functions (cycles)
10.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 06/2019, A5E44903486B AB 641
