6.10 Editing a program
With the editor, you are able to render, supplement, or change part programs.
Note
Maximum block length
The maximum block length is 512 characters.
Calling the editor
● The editor is started via the "Program correction" softkey in the "Machine" operating area.
You can directly change the program by pressing the <INSERT> key.
● The editor is called via the "Open" softkey as well as with the <INPUT> or <Cursor right> key
in the "Program manager" operating area.
● The editor opens in the "Program" operating area with the last executed part program, if this
was not explicitly exited via the "Close" softkey.
Note
● Please note that the changes to programs saved in the NC memory take immediate
effect.
● If you are editing on a local drive or external drives, you can also exit the editor without
saving, depending on the setting. Programs in the NC memory are always automatically
saved.
● Exit the program correction mode using the "Close" softkey to return to the "Program
manager" operating area.
See also
Editor settings (Page 186)
Correcting a program (Page 162)
Opening and closing the program (Page 782)
Generating a G code program (Page 268)
6.10.1 Searching in programs
You can use the search function to quickly arrive at points where you would like to make
changes, e.g. in very large programs.
Various search options are available that enable selective searching.
Machining the workpiece
6.10 Editing a program
Turning
178 Operating Manual, 06/2019, A5E44903486B AB
