9.19 Example: Standard machining
General information
The following example is described in detail as ShopTurn program. A G code program is
generated in the same way; however, some differences must be observed.
If you copy the G code program listed below, read it into the control and open it in the editor, then
you can track the individual program steps.
Machine manufacturer
Under all circumstances, observe the machine manufacturer’s instructions.
Tools
The following tools are saved in the tool manager:
Roughing tool_80 80°, R0.6
Roughing tool_55 55°, R0.4
Finishing tool 35°, R0.4
Plunge cutter Plate width 4
Threading tool_2
Drill_D5 ∅5
Miller_D8 ∅8
Adapt the cutting data to the tools used and the specific application conditions at the machine.
Blank
Dimensions: ∅90 x 120
Material: Aluminum
Creating a ShopTurn program
9.19 Example: Standard machining
Turning
326 Operating Manual, 06/2019, A5E44903486B AB
