5.4 Positioning axes
In order to implement simple machining sequences, you can traverse the axes to certain
positions in manual mode.
The feedrate / rapid traverse override is active during traversing.
Procedure
1. If required, select a tool.
2. Select the "JOG" operating mode.
3. Press the "Positions" softkey.
4. Enter the target position or target angle for the axis or axes to be trav‐
ersed.
5. Specify the desired value for the feedrate F.
- OR -
Press the "Rapid traverse" softkey.
The rapid traverse is displayed in field "F".
6. Press the <CYCLE START> key.
The axis is traversed to the specified target position.
If target positions were specified for several axes, the axes are traversed
simultaneously.
Working in manual mode
5.4 Positioning axes
Turning
144 Operating Manual, 06/2019, A5E44903486B AB
