16.2 Measuring the tool

All the options of the manual and automatic measurement are available to determine the tool

offset data (see also Section "Measuring the tool (Page 105)").

Procedure

1. "Manual Machine" is active.

2. Press the "Meas. tool" softkey.

3. Select the the required measuring function via the vertical softkey bar

and press the appropriate softkey.

Working with Manual Machine

16.2 Measuring the tool

Turning

Operating Manual, 06/2019, A5E44903486B AB 859
