Parameter Description Unit
Allowance Allowance for pre-finishing - (only for ∇∇∇)
Yes
U1 contour allowance
No
s
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
Positive value: Compensation allowance is retained
Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
Yes
No
XA
XB
ZA
ZB
with limited machining area only, yes:
1. Limit XA ∅
2. Limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1. Limit ZA
2. Limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
Relief cuts Machine relief cuts
Yes
No
FR Insertion feedrate, relief cuts
* Unit of feedrate as programmed before the cycle call
10.3.10 Plunge-cutting (CYCLE952)
Function
The "Grooving" function is used to machine grooves of any shape.
Before you program the groove, you must define the groove contour.
If a groove is wider than the active tool, it is machined in several cuts. The tool is moved by a
maximum of 80% of the tool width for each groove.
Blank
When grooving, the cycle takes into account a blank that can consist of a cylinder, an allowance
on the finished-part contour or any other blank contour.
Note
In order to avoid collisions between tools and workpieces due to positioning motions, the
programmed blank contour must match the real blank.
Programming technology functions (cycles)
10.3 Contour turning
Turning
Operating Manual, 06/2019, A5E44903486B AB 467
