16.7 Simulation and simultaneous recording
For more complex machining processes, you can check the result of your inputs with the aid of
the simulation, without having to traverse the axes (see Section "Simulating machining
(Page 235)"). The execution of the work steps is graphically displayed on the screen during this
period.
Software option
You require the option "Simultaneous recording ShopTurn (real-time simula‐
tion)" for the simultaneous recording of the work steps.
Note
In "Manual Machine", you can simulate a work step with an already opened and filled out
parameter screen form.
Setting up a blank shape
For the graphical display, a pre-defined blank shape is used. Just the same as under
simultaneous recording, in automatic and simulation you can change the blank as required (see
Section "Blank display (Page 249)").
Working with Manual Machine
16.7 Simulation and simultaneous recording
Turning
Operating Manual, 06/2019, A5E44903486B AB 873
