Tool type Additional parameters
131 Angle head cutter with cor‐
ner rounding
Geometry length (length X, length Y, length Z)
Corner radius
Wear length (Δ length X, Δ length Y, Δ length Z)
Adapter length (length X, length Y, length Z)
V (direction vector 1 - 6)
Vector X, vector Y, vector Z
140 Face milling External radius
Tool angle
155 Bevel cutter Taper angle
156 Bevel cutter with corner
rounding
Corner radius
Taper angle
157 Conical die-milling cutter Taper angle
700 slotting saw Geometry length (length X, length Y, length Z)
Wear length (Δ length X, Δ length Y, Δ length Z)
Adapter length (length X, length Y, length Z)
Geometry (slot width, projection)
Wear (slot width, projection)
You can use the configuration file to specify the data to be displayed for specific tool types in
the "Additional Data" window.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. The tool list is opened.
2. In the list, select an appropriate tool, e.g. an angle head cutter.
3. Press the "Additional data" softkey.
The "Additional Data - ..." window opens.
The "Additional data" softkey is only active if a tool for which the "Addi‐
tional Data" window is configured is selected.
13.5.2 Creating a new tool
When creating a new tool, the "New tool - favorites" window offers you a number of selected tool
types, known as "favorites".
If you do not find the desired tool type in the favorites list, then select the milling, drilling, turning
or special tool via the corresponding softkeys.
Tool management
13.5 Tool list
Turning
732 Operating Manual, 06/2019, A5E44903486B AB
