8.8 Selection of the cycles via softkey

Overview of the machining steps

The following machining steps are available.

All of the cycles/functions available in the control are shown in this display. However, at a

specific system, only the steps possible corresponding to the selected technology can be

selected.

⇒

⇒ ⇒

Creating a G code program

8.8 Selection of the cycles via softkey

Turning

Operating Manual, 06/2019, A5E44903486B AB 273
