Parameter Description Unit
ZD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
● Yes
U1 contour allowance
● No
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is kept
● Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
* Unit of feedrate as programmed before the cycle call
Hidden parameters
Parameter Description Value Can be set in SD
Residual material With subsequent residual material removal No
SC Safety clearance x
DI Continuous cut - (only for ∇) 0
Set machining area
limits
Set machining area limits No
N Number of grooves 1
Machine manufacturer
Please refer to the machine manufacturer's specifications.
10.3.11 Plunge-cutting rest (CYCLE952)
Function
The "Grooving residual material" function is used when you want to machine the material that
remained after grooving along the contour.
Programming technology functions (cycles)
10.3 Contour turning
Turning
Operating Manual, 06/2019, A5E44903486B AB 473
