During grooving ShopTurn, the cycle automatically detects any residual material and generates
an updated blank contour. For a G code program, the function must have been previously
selected. Material that remains as part of the finishing allowance is not residual material. The
"Grooving residual material" function allows you to remove unwanted material with a suitable
tool.
Software option
To machine residual material, you require the "Residual material detection and
machining" option.
Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Contour turning" softkey.
3. Press the "Grooving residual material" softkey.
The "Grooving residual material" input window is opened.
G code program parameters ShopTurn program parameters
PRG
● Name of the program to be generated
● Auto
Automatic generation of program names
T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane – (only for
longitudinal machining direc‐
tion)
mm F Feedrate mm/rev
SC Safety clearance mm S / V Spindle speed or constant cut‐
ting rate
rpm
m/min
F Feedrate *
CON Name of the updated blank contour for residual
material machining (without the attached char‐
acter "_C" and double-digit number)
Residual
material
With subsequent residual material removal
● Yes
● No
CONR Name to save the updated unmachined-part
contour for residual material removal - (only
"Yes" for residual material removal)
Programming technology functions (cycles)
10.3 Contour turning
Turning
474 Operating Manual, 06/2019, A5E44903486B AB
