Parameter Description Unit
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
Machining
direction
● Face
● Longitudinal
Position
● front
● rear
● Internal
● external
D Maximum depth infeed - (only for ∇) mm
XDA First grooving limit tool (abs) – (only for face machining direction) mm
XDB Second grooving limit tool (abs) – (only for face machining direction) mm
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇) mm
UZ Finishing allowance in Z – (only for UX) mm
DI For zero: Continuous cut - (only for ∇) mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
● Yes
U1 contour allowance
● No
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is retained
● Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
● Yes
● No
XA
XB
ZA
ZB
with limited machining area only, yes:
1. Limit XA ∅
2. Limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1. Limit ZA
2. Limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves (inc) mm
* Unit of feedrate as programmed before the cycle call
Programming technology functions (cycles)
10.3 Contour turning
Turning
Operating Manual, 06/2019, A5E44903486B AB 475
