14.7 Displaying the program in the Preview.

You can show the content on a program in a preview before you start editing.

Procedure

1. Select the "Program manager" operating area.

2. Select a storage location and place the cursor on the relevant program.

3. Press the ">>" and "Preview window" softkeys.

The "Preview: ..." window opens.

4. Press the "Preview window" softkey again to close the window.

Managing programs

14.7 Displaying the program in the Preview.

Turning

796 Operating Manual, 06/2019, A5E44903486B AB
