Page #103 background imageLoading...
Page #103 background image
4.4.3 Setting the zero offset
You can enter a new position value in the actual value display for individual axes when a
settable zero offset is active.
The difference between the position value in the machine coordinate system MCS and the new
position value in the workpiece coordinate system WCS is saved permanently in the currently
active zero offset (e.g. G54).
Relative actual value
Further, you also have the possibility of entering position values in the relative coordinate
system.
Note
The new actual value is only displayed. The relative actual value has no effect on the axis
positions and the active zero offset.
Resetting the relative actual value
Press the "Delete REL" softkey.
The actual values are deleted.
The softkeys to set the zero point in the relative coordinate system are only available if the
corresponding machine data is set.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Precondition
The controller is in the workpiece coordinate system.
The actual value can be set in both the Reset and Stop state.
Note
Setting the WO in the Stop state
If you enter the new actual value in the Stop state, the changes made are only visible and only
take effect when the program is continued.
Setting up the machine
4.4 Settings for the machine
Turning
Operating Manual, 06/2019, A5E44903486B AB 103
