The following conditions must be met before you can switch between units of measurement:
● The corresponding machine data are set.
● All channels are in the reset state.
● The axes are not being traversed via "JOG", "DRF", and the "PLC".
● Constant grinding wheel peripheral speed (GWPS) is not active.
Machine manufacturer
Please observe the information provided by the machine manufacturer.
Further information
Further information about switching the measurement unit can be found in the Basic Functions
function manual.
Procedure
1.
Select the mode <JOG> or <AUTO> in the "Machine" operating area.
2. Press the menu forward key and the "Settings" softkey.
A new vertical softkey bar appears.
3. Press the "Switch to inch" softkey.
A prompt asks you whether you really want to switch over the unit of
measurement.
4. Press the "OK" softkey.
The softkey label changes to "Switch to metric".
The unit of measurement applies to the entire machine.
5. Press the "Switch to metric" softkey to set the unit of measurement of the
machine to metric again.
See also
Default settings for manual mode (Page 152)
Setting up the machine
4.4 Settings for the machine
Turning
102 Operating Manual, 06/2019, A5E44903486B AB
