4.9 Monitoring axis and spindle data
4.9.1 Specify working area limitations
Using the "Working area limitation" function you can limit the range within which a tool should
traverse in all channel axes. This function allows you to set up protection zones in the working
area that are inhibited for tool motion.
In this way, you are able to restrict the traversing range of the axes in addition to the limit
switches.
Requirements
You can only make changes in "AUTO" mode when in the RESET condition. These changes
are then immediate.
You can make changes in "JOG" mode at any time. These changes, however, only become
active at the start of a new motion.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Setting data" softkey.
The "Working Area Limitation" window appears.
3. Place the cursor in the required field and enter the new values via the
numeric keyboard.
The upper or lower limit of the protection zone changes according to your
inputs.
4. Click the "active" checkbox to activate the protection zone.
Note
You will find all of the setting data in the "Start-up" operating area under "Machine data" via the
menu forward key.
4.9.2 Editing spindle data
The speed limits set for the spindles that must not be under- or overshot are displayed in the
"Spindles" window.
Setting up the machine
4.9 Monitoring axis and spindle data
Turning
Operating Manual, 06/2019, A5E44903486B AB 125
