7.5 Different views of the workpiece
In the graphical display, you can choose between different views so that you constantly have
the best view of the current workpiece machining, or in order to display details or the overall
view of the finished workpiece.
The following views are available:
● Side view
● Half cut view
● Face view
● 3D view (with option)
● 2-window
● Machine space (with option)
Note
Simulation in half-section view
The "half-section" view in the simulation allows a more precise observation of the internal
turning operations. This view was not conceived for monitoring milling operations. The display
of milling operations can lead to excessive simulation times.
7.5.1 Side view
Displaying a side view
1. Simultaneous recording or simulation is started.
2. Press the "Side view" softkey.
The side view shows the workpiece in the Z-X plane.
Changing the display
You can increase or decrease the size of the simulation graphic and move it, as well as change
the segment.
Simulating machining
7.5 Different views of the workpiece
Turning
Operating Manual, 06/2019, A5E44903486B AB 245
