In addition to the offset (course and fine), the rotation, scaling and mirroring defined using this
are also displayed.
This window is generally used only for monitoring.
Display of active work offsets
Work offsets
DRF Displays the handwheel axis offset.
Rotary table reference Displays the additional work offsets programmed with $ P_PART‐
FRAME.
Basic reference Displays the additional work offsets programmed with $P_SETFRAME.
Access to the system offsets is protected via a keyswitch.
External WO frame Displays the additional work offsets programmed with $P_EXTFRAME.
Total base WO Displays all effective basis offsets.
G500 Displays the work offsets activated with G54 - G599.
Under certain circumstances, you can change the data using "Set WO",
i.e. you can correct a zero point that has been set.
Tool reference Displays the additional work offsets programmed with $P_TOOLFRAME.
Workpiece reference Displays the additional work offsets programmed with $P_WPFRAME.
Programmed WO Displays the additional work offsets programmed with $P_PFRAME.
Cycle reference Displays the additional work offsets programmed with $P_CYCFRAME.
Total WO Displays the active work offset, resulting from the total of all work offsets.
Procedure
1. Select the "Parameter" operating area.
2 Press the "Work offset" and "Overview" softkeys.
The "Work offsets - Overview" window opens.
4.8.3 Displaying and editing base zero offset
The defined channel-specific and global base offsets, divided into coarse and fine offsets, are
displayed for all set-up axes in the "Zero offset - Base" window.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Setting up the machine
4.8 Zero offsets
Turning
Operating Manual, 06/2019, A5E44903486B AB 119
