Parameter Description Unit
DZ Maximum depth infeed
Lift mode Lift mode before new infeed
If the machining operation requires several points of insertion, the retraction height can be
programmed:
● To retraction plane
● Z0 + safety clearance
When making the transition to the next insertion point, the tool returns to this height. If
there are no elements larger than Z0 (X0) in the pocket area, then Z0 (X0) + safety
clearance can be programmed as the lift mode.
mm
mm
10.5.12 Milling contour spigot (CYCLE63)
Function
You can use the "Mill spigot" function to mill any spigots on the face or peripheral surface.
Before you mill the spigot, you must first enter a blank contour and then one or more spigot
contours. The blank contour defines the area, outside of which there is no material, i.e. there,
the tool moves with rapid traverse. Material is then removed between the blank contour and
spigot contour.
Note
Execution from external media
If you execute programs from an external drive (e.g. local drive or network drive), you require
the "Execution from external storage (EES)" function.
For additional information, please refer to the following references:
SINUMERIK Operate Commissioning Manual
Clamping the spindle
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Programming technology functions (cycles)
10.5 Contour milling
Turning
596 Operating Manual, 06/2019, A5E44903486B AB
