4.8.6 Deleting a zero offset
You have the option of deleting work offsets. This resets the entered values.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Work offset" softkey.
...
3. Press the "Overview", "Basis" or "G54…G599" softkey.
4. Press the "Details" softkey.
5. Position the cursor on the work offset you would like to delete.
6. Press the "Clear offset" softkey.
A confirmation prompt is displayed as to whether you really want to de‐
lete the work offset.
7. Press the "OK" softkey to confirm that you wish to delete the work offset.
4.8.7 Measuring the workpiece zero
Procedure
1. Select the "Parameters" operating area and press the "Zero offset" soft‐
key.
2. Press the "G54...G599" softkey and select the zero offset in which the
zero point is to be saved.
3. Press the "Workpiece zero" softkey.
You change to the "Set Edge" window in the "JOG" mode.
Setting up the machine
4.8 Zero offsets
Turning
Operating Manual, 06/2019, A5E44903486B AB 123
