Precondition
Software options
You require the "programSYNC" option to generate and edit synchronized pro‐
grams in the multi-channel editor as well as for the multi-channel functions in
the "Machine" operating area.
Example
Your machine has 6 channels.
You configure channels 1 - 4 for the multi-channel view and define the display sequence (e.g.
1,3,4,2).
Using the <CHANNEL> key, advance the channel in the "Machine" operating area - you obtain
the following views: Channels "1" and "3", channels "3" and "4", channels "4" and "2". Channels
"5" and "6" are not displayed in the multi-channel view.
In the single-channel view, toggle between all of the channels (1...6) without taking into account
the configured sequence for the multi-channel view.
Procedure
1. Select the "Machine" operating area.
2. Select the operating mode "JOG", "MDA" or "AUTO".
3. Press the menu forward key and the "Settings" softkey.
4. Press the "Multi-channel function" softkey.
The "Settings for the multi-channel functionality" window is opened.
11.2.7 Synchronizing programs
Using the synchronized view, you have the possibility of obtaining an overview of the time
sequence of a program. In this case, program instructions are evaluated to coordinate channels
and are arranged in parallel in the editor view.
As a result of the synchronized view of the programs, you can easily identify at which locations
the programs are synchronized in the various channels.
Multi-channel machining
11.2 Multi-channel support
Turning
Operating Manual, 06/2019, A5E44903486B AB 687
To Next Page
