The transformation refers to the current machining surface (turning, face ..., peripheral ...).
Therefore it must be selected prior to the transformation (e.g. with Straight/Circle => Tool).
Note
Transformations with virtual axes
Please note that when selecting TRANSMIT or TRACYL offsets, scaling and mirroring, the real
Y axis is not transferred into the virtual Y axis.
Offsets, scalings and mirroring of the virtual Y axis are deleted for TRAFOOF.
Procedure for work offset, offset, rotation, scaling, mirroring or rotation C axis.
1. The ShopTurn program has been created and you are in the editor.
2. Press the "Various" and "Transformation" softkeys.
3. Press the "Work offsets” softkey.
The "Work offsets" input window opens.
- OR -
Press the "Offset" softkey.
The "Offset" input window opens.
- OR -
Press the "Rotation" softkey.
The "Rotate" input window opens.
- OR -
Press the "Scaling" softkey.
The "Scaling" input window opens.
- OR -
Press the "Mirroring" softkey.
The "Mirroring" input window opens.
- OR -
Press the "Rotation C axis" softkey.
The "Rotation C axis" input window opens.
Programming technology functions (cycles)
10.7 Additional cycles and functions in ShopTurn
Turning
632 Operating Manual, 06/2019, A5E44903486B AB
