Procedure
1. The ShopTurn program to be processed has been created and you are
in the editor.
2. Press the "Drilling" and "Drill centric" and "Thread centric" softkeys.
The "Centric tapping" input window opens.
Parameters Description Unit
T Tool name
D Cutting edge number
F Feedrate mm/min
mm/rev
Table Thread table selection:
● without
● ISO metric
● Whitworth BSW
● Whitworth BSP
● UNC
Selection Selection, table value:
● M1 - M68 (ISO metric)
● W3/4"; etc. (Whitworth BSW)
● G3/4"; etc. (Whitworth BSP)
● 1" - 8 UNC; etc. (UNC)
P
- (selection
only possible for
table selection
"without")
Pitch ...
● in MODULUS: MODULUS = Pitch/π
● in mm/rev
● in inch/rev
● in turns per inch: Used with pipe threads, for example.
When entered per inch, enter the integer number in front of the decimal point in the first
parameter field and the figures after the decimal point as a fraction in the second and
third field.
The pitch is determined by the tool used.
MODULUS
mm/rev
in/rev
turns/"
S / V Spindle speed or
constant cutting rate
rpm
m/min
SR Spindle speed for retraction rev/min
VR Constant cutting rate for retraction m/min
Programming technology functions (cycles)
10.7 Additional cycles and functions in ShopTurn
Turning
630 Operating Manual, 06/2019, A5E44903486B AB
