Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Positions" and "Row" softkeys.
The "Position row" input window opens.
Parameter Description Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Machining
surface
(only for Shop‐
Turn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for Shop‐
Turn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
X0
Y0
α0
(only for G Code)
X coordinate of the reference point X (abs)
This position must be programmed absolutely in the 1st call.
Y coordinate of the reference point Y (abs)
This position must be programmed absolutely in the 1st call.
Angle of rotation of the line referred to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
Degrees
Z0
X0
Y0
α0
(only for Shop‐
Turn)
Face C:
Z coordinate of the reference point (abs)
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
Programming technology functions (cycles)
10.1 Drilling
Turning
Operating Manual, 06/2019, A5E44903486B AB 391
