Parameter Description Unit
Z0
CP
X0
Y0
α0
(only for Shop‐
Turn)
Face Y:
Z coordinate of the reference point (abs)
Positioning angle for machining area
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that machining
is possible on the machine.
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
X0
Y0
Z0
α0
(only for Shop‐
Turn)
Peripheral surface C:
Cylinder diameter ∅ (abs)
Y coordinate of the reference point – first position (abs)
Z coordinate of the reference point – first position (abs)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
X0
C0
Y0
Z0
α0
(only for Shop‐
Turn)
Peripheral surface Y:
X coordinate of the reference point (abs)
Positioning angle for machining surface
Y coordinate of the reference point – first position (abs)
Z coordinate of the reference point – first position (abs)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
L0
L
N
Distance of the 1st position to reference point
Distance between the positions
Number of positions
mm
mm
Programming technology functions (cycles)
10.1 Drilling
Turning
392 Operating Manual, 06/2019, A5E44903486B AB
