•ThenavigationsensorisinstalledintotheST90software.Therelevantinterface
parametersandphysicallocationpropertiesaredened.
Context
Anyinformationinadatagram,forexamplethecurrentdepth,maybeprovidedin
differentdatagramsfromseveralsensors.Duetoanumberofreasons(environmental
conditions,installation,conguration,accuracy,etc.),thenumericalvaluesprovidedcan
bedifferentfromonesensortoanother.
SeveralsensorareprovidedontheSensorCongurationpage,oneforeachtypeof
information.SelectthesensoryouwishtocongureintheSensorlist.Foreachtype,you
candeneaprioritysensorbyrearrangingthedatagramsinalist.Youcanalsodene
manualvaluesincaseasensorisunserviceable,ornotinstalled.
TheST90cancommunicatewithseveraldifferentsensortypes.OntheSensor
InstallationpageyoudenewhichexternalsensorsyourST90willimportinformation
from.Youmustalsodecidewhichdatagramformatsthatwillbeaccepted.
Note
WhenyouworkintheInstallationdialogbox,youmustalwaysselectApplytosavethe
changesmadeonapage.Youmustdothisbefore
youcontinueworkingonadifferent
page.
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectSensorConguration.
ObservethattheSensorCongurationpageopens.
4SelectthesensoryouwishtocongureintheSensorlist.
5Ifyouwishtousethebuilt-indatagrampriority,selectAuto.
•WithAutoenabled,theprioritylistisused.Informationisimportedfromthe
sensoratthetopofthelist.Ifthesensorfailstoprovideinformationformore
than20seconds,datafromthenextsensorisused.
•WithAutodisabled,theprioritylistisnotused.Informationisimportedfromthe
sensoratthetopofthelist.Allothersensorsareignored.
6Ifyouwishtocontrolthedatagramprioritymanually,donotselectAuto.
Tochangethepriorityforagivendatagram,selectit,andchangeitslocationon
thelistusingthearrowbuttons.
