442703/B

193

ØverlandUPC-3005Connections

TheØverlandUPC-3005seriallinesplitteroffersoneinputandeightRS-232and

RS-422outputs.Theseriallinesplitterrequiresadedicatedpowersupplyproviding

15to30VDC.

APowerrequirements:+15-30VDC

BInput

COutputs:3xRS-232

DOutputs:5xRS-422

Note

Thisinformationwascopiedfromthemanufacturer’ s

documentation.Thetechnicalspecicationsmay

bechangedwithoutpriornotice.Toensurethat

yourinformationiscorrect,alwaysconsultthe

manufacturer’ sowndocuments.

Relatedtopics

ØverlandUPC-3005Seriallinesplitterdescription,

page191

ØverlandUPC-3005Technicalspecications,page192

ØverlandUPC-3005Connections,page193

ØverlandUPC-3005Dimensions,page194

Cablelayoutandinterconnections
